Matrix 55 Landscaping Fabric
PROFESSIONAL GRADE
Matrix 55 landscaping fabric is a three layer, technologically advanced textile created to actually deliver on the functionality expected from landscaping cloth. Each layer has a specific purpose, and when melded together, create a fabric that allows air and water flow but prevents plant sprouts from penetrating.
Only 3 layer product with 2 distinct structures
Layer 1 (Top) = non-woven fabric
UV protected Non-woven made on state-of-the-art equipment to allow even balanced strength in both machine and cross direction. It has excellent durability, a soft feel and a non-slip surface that provides increased safety in wet conditions.
Layer 2 (Middle) = Nex Matrix
Designed to both catch and block all types of weeds and reinforce the top and bottom layers. Mesh pockets also help control soil erosion.
Layer 3 (Bottom) = non-woven fabric
UV protected, evenly balanced non-woven bottom layer with excellent strength. This layer of fabric has been designed to perform in all soil conditions and climates.
- • Excellent weed and erosion control
- • UV stabilized to last longer
- • Air, water and nutrients pass easily though the matrix to maintain healthy soil conditions
- • Distributes water evenly with a steady slow-drip to soil underneath
- • Extra strong grid design helps block weeds from penetrating fabric
- • Easy to cut and install, stays in place after installation
- • Environmentally friendly material
Matrix 55 Technical/Comparative Data:
| Specification |
ASTM Standard |
Matrix 55 Typical Value |
Non-Woven Fabric Typical Value |
Film Fabric Typical Value |
| Weight (GSM) |
D3776 |
55.0 |
50.0 |
50.0 |
| Thickness (mm) |
D1777 |
0.52 |
0.23 |
0.22 |
| Tensile Strength (lbs) |
D5034 |
40.9 MD 31.8 CD |
14.8 MD 10.9 CD |
8.6 MD 5.1 CD |
| Trapezoidal Tear (lbs) |
D4533 |
13.6 MD 13.9 CD |
7.8 MD
5.2 CD |
3.5 MD 3.0 CD |
| Air Permeability (CFM/FT2) |
D737 |
357.0 |
280.0 |
480.0 |
| Water Permeability (Ltr/M2/Sec | Permittivity) |
D4491 |
65.2 | 1.05 |
10.8 | 0.58 |
224 | 6.45 |
NexMatrix can be manufactured in a wide variety of colors
